Honda Pilot II facelift (2011-2015) driver's door power tailgate switch wiring diagram
This page shows the only wiring diagram for the component.driver's door power tailgate switch, which is found in the car Honda Pilot II facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver's door power tailgate switch wiring diagram (1 of 1)
11 12 PNK WIRE
AUXILIARY UNDER-HOOD FUSE/RELAY FUSE 8 BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR POWER TAILGATE SWITCH
FULL LATCH SWITCH
FUSE 1
GRN WIRE
HOT AT ALL TIMES
INSIDE TAILGATE SWITCH
J/C
LT BLU WIRE
LT GRN WIRE
NEUTRAL SWITCH
ORG/ WIRE
PNK 1 2 3 4 5 6 WIRE
PNK WIRE
POWER TAILGATE CLOSER UNIT (LEFT SIDE OF TAILGATE)
POWER TAILGATE LATCH/ RATCLUT
PPL
RATCHET SWITCH
RED WIRE
RELEASE SWITCH
SWITCH HALF LATCH SWITCH
TAILGATE OUTER HANDLE SWITCH
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION)
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power tailgate circuit (2 of 2) -> DRIVER'S DOOR POWER TAILGATE SWITCH
