Honda Pilot II facelift (2011-2015) drive circuit Wiring diagram
This page shows the only wiring diagram for the component.drive circuit, which is found in the car Honda Pilot II facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive circuit (1 of 1)
AREA)
BLK WIRE
BLU WIRE
COMBI
COMPUTER DATA LINES SYSTEM
CONTROLLER
CONTROLLER AREA NETWORK CONTROLLER
DRIVE CIRCUIT
FAST
FR FR FR
FR FR WIP WIP FR GND MIST HI&LO WASH SW SW WIPER
FR WASHER MTR
FR WIP FR WIP WIPER WIPER WIP INT INT&LO (WIPER) LO (AS) HI VR+ SW SW
FUSE 38 FUSE 10
GAUGE CONTROL MODULE
GRN WIRE
HOT IN ON OR START
INDICATOR
METER WIPER WIPER
MICU
MIRRORS SYSTEM
NETWORK
OF DASH)
OFF WASH WINDSHIELD WASHER SWITCH
ORG/ WIRE
PARK
RED WIRE
RR WASHER MTR
RUN WIRE
S- P- P- P- S- GND GND GND GND GND
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE
UNIT)
WASHER FLUID LEVEL INDICATOR
WASHER FLUID LEVEL SWITCH (IF EQUIPPED)
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD/ REAR WINDOW WASHER MOTOR (ON WASHER FLUID RESERVOIR)
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> DRIVE CIRCUIT
