Starting circuit for Honda Pilot II (2008-2011)
Starting circuit (1 of 2)
2 2 STARTER STARTER CUT CUT RELAY 1
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
ELD UNIT
FUSE 23
GRN WIRE
LT GRN WIRE
MULTI FUSE
POWER DISTRIBUTION SYSTEM
STARTER
STARTER MOTOR
STARTER SOLENOID
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION)
UNDER-HOOD FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
Starting circuit (2 of 2)
ACC CUT RELAY (UNDER LEFT SIDE OF DASH)
AUXILIARY UNDER-DASH FUSE HOLDER STS OF DASH)
BLU/WHT WIRE
BRN WIRE
GRN WIRE
IGNITION SWITCH
LOCK
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PCM (RIGHT SIDE OF ENGINE COMPT)
POWER DISTRIBUTION SYSTEM
RED WIRE
RLY CTRL
RLY IN
ST SW SIG
START CUT RELAY 2 (UNDER UNDERDASH FUSE/RELAY BOX)
WHT WIRE
YEL WIRE
