Heated seats circuit, heated second row seats for Honda Pilot II (2008-2011)
Heated seats circuit, heated second row seats
AUXILIARY UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 21
FUSE 36
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
LEFT SECOND ROW SEAT HEATER
LEFT SECOND ROW SEAT HEATER RELAY (HIGH)
LEFT SECOND ROW SEAT HEATER RELAY (LOW)
LEFT SECOND ROW SEAT HEATER SWITCH
LT BLU WIRE
LT GRN WIRE
MICU
ON INDICATORS
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT SECOND ROW SEAT HEATER
RIGHT SECOND ROW SEAT HEATER RELAY (HIGH)
RIGHT SECOND ROW SEAT HEATER SWITCH
SEAT BACK)
SEAT CUSHION)
SWITCH ILLUMINATION
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
