Hands free module circuit, honda accessory for Honda Pilot II (2008-2011)
Hands free module circuit, honda accessory
+B 12 13
+B HFT
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 IG 2 HFT HFT COM
15 16 17 18 GND
5 6 7 8 GND HFT HFT MUTE MIC -
AUDIO
AUDIO+ MIC SH MIC + MIC - +B HFT HBRAKE SW GND HFT
AUTOMATIC DIMMING INSIDE MIRROR CONNECTOR 1
AUTOMATIC DIMMING INSIDE MIRROR CONNECTOR 2
BLK WIRE
BLK/YEL WIRE
BLU WIRE
GAUGE CONTROL MODULE
GRY WIRE
HANDSFREE LINK SWITCH
HFT MUTE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE 22 BOX (RIGHT SIDE OF ENGINE COMPT)
HOT IN ON UNDER-DASH FUSE/RELAY FUSE 36 BOX (UNDER LEFT SIDE OF DASH) MICU
IG 2 HFT
LT BLU WIRE
LT GRN WIRE
MIC + HFT COM AUDIO+ AUDIO-
ORG/ WIRE
PARKING BRAKE SWITCH (TOP OF PARKING BRAKE PEDAL ASSEMBLY)
RED WIRE
WHT WIRE
YEL WIRE
