Car Wiring Diagrams for Compass circuit for Honda Pilot II (2008-2011)

AUDIO UNIT BLK WIRE BLU WIRE BRN WIRE DISP RX+ DISP RX- DISP TX+ DISP TX- ELECTRICAL COMPASS UNIT (CENTER REAR OF ROOF) FUSE 10 GND RX+ RX- TX+ TX- GRY WIRE HOT IN ON OR START ORG/ WIRE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) YEL WIRE
