Car Wiring Diagrams for B-can circuit/uart communication line for Honda Pilot II (2008-2011)

AUDIO UNIT AUTOMATIC LIGHTING CONTROL UNIT (UNDER LEFT SIDE OF DASH) B-CAN HI B-CAN LO BLK WIRE BRN WIRE CLIMATE CONTROL CLIMATE CONTROL UNIT FRONT PASSENGER'S POWER WINDOW SWITCH (IN FRONT ROOF CONSOLE) GAUGE CONTROL MODULE HANDSFREELINK CONTROL UNIT (UNDER CENTER CONSOLE) HVAC CONTROL UNIT IMMOBILIZER KEYLESS CONTROL UNIT (IN STEERING COLUMN) J/C LT GRN WIRE MANUAL A/C MICU SERVICE CHECK CONNECTOR MOONROOF CONTROL MODULE PARKING AND BACK-UP SENSOR CONTROL UNIT (UNDER LEFT SIDE OF DASH) POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT) POWER TAILGATE CONTROL UNIT (LEFT SIDE OF CARGO AREA) POWER WINDOW MASTER SWITCH PPL REMOTE STARTING SYSTEM CONNECTOR (OPTION CONNECTOR) (UNDER LEFT SIDE OF DASH) S GND UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) MICU WHT WIRE
