Honda Pilot II (2008-2011) rear hvac control panel Wiring diagrams
This page contains all the electrical diagrams for the component. rear hvac control panel, in which he is found in the car Honda Pilot II (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear hvac control panel (1 of 2)
1 2 3 4 5 6 7 8 9 10 ILLUMINATION+
AMD-P
AUXILIARY UNDER-HOOD
BLK WIRE
BLU WIRE
BRN/WHT WIRE
BUS-DATA
FUSE FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
ILLUMINATION
LT BLU WIRE
M-COOL
M-HEAT
M-HOT
M-VENT
ORG/ WIRE
PNK WIRE
PPL
REAR AIR MIX CONTROL MOTOR (UNDER CENTER CONSOLE)
REAR BLOWER MOTOR (UNDER CENTER CONSOLE)
REAR BLOWER MOTOR RELAY
REAR BLOWER POWER
REAR HVAC CONTROL PANEL
REAR MODE CONTROL MOTOR (UNDER CENTER CONSOLE)
RED WIRE
RED/GRN WIRE
S-COM
TRANSISTOR (UNDER CENTER CONSOLE)
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 3) -> REAR HVAC CONTROL PANEL
Wiring diagram rear hvac control panel (2 of 2)
