Honda Pilot II (2008-2011) lock unlock pg sg Wiring diagram

+B BACK UP +B INTR 3 4 B-CAN LO B-CAN HI ANTENNA AS COURTESY B-CAN VBU BLK WIRE BLU WIRE CARGO AREA LIGHT CARGO LT- COMPUTER DATA LINES SYSTEM DOOR DOOR MULTIPLEX B-CAN CONTROL UNIT HI LO DR COURTESY DRIVER'S DOOR COURTESY LIGHT PNK WIRE DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR) DRSWDR DRSWAS DRSWRD DRSWRA FRONT PASSENGER'S DOOR COURTESY LIGHT FRONT PASSENGER'S DOOR SWITCH (ON RIGHT "B" PILLAR) G/H SW GRY WIRE HATCH GLASS LATCH TAILGATE SWITCH LATCH SWITCH IG KEY SW INSIDE TAILGATE SWITCH (POWER TAILGATE) INTR LT- LEFT REAR DOOR COURTESY LIGHT LEFT REAR DOOR SWITCH (ON LEFT "C" PILLAR) LOCK LOCK UNLOCK PG SG LT BLU WIRE LT GRN WIRE MICU OFF ORG/ WIRE PNK WIRE POWER WINDOW MASTER SWITCH RED WIRE RIGHT REAR DOOR COURTESY LIGHT RIGHT REAR DOOR SWITCH RR AS COURTESY RR DR COURTESY T/G SW UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) W/ POWER TAILGATE W/O POWER TAILGATE WHT WIRE YEL WIRE
