Honda Pilot II (2008-2011) honda accessory with hfl system Wiring diagram
This page shows the only wiring diagram for the component.honda accessory with hfl system, which is found in the car Honda Pilot II (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram honda accessory with hfl system (1 of 1)
A/T REVERSE RELAY
AUTOMATIC DIMMING INSIDE
AUTOMATIC DIMMING INSIDE MIRROR CONNECTOR 1 (OPTION CONNECTOR)
BLK WIRE
FACTORY
FUSE 10
FUSE 36
HAC
HANDSFREELINK SWITCH
HONDA ACCESSORY
HONDA ACCESSORY FACTORY
HONDA ACCESSORY WITH HFL SYSTEM
HOT IN ON
HOT IN ON OR START
MICU
MIRROR
ORG/ WIRE
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit -> HONDA ACCESSORY WITH HFL SYSTEM
