Honda Pilot II (2008-2011) console console accessory accessory power power socket b socket a relay relay Wiring diagram
This page shows the only wiring diagram for the component.console console accessory accessory power power socket b socket a relay relay, which is found in the car Honda Pilot II (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram console console accessory accessory power power socket b socket a relay relay (1 of 1)
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CARGO AREA ACCESSORY POWER SOCKET RELAY
CONSOLE CONSOLE ACCESSORY ACCESSORY POWER POWER SOCKET B SOCKET A RELAY RELAY
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
FROM AUXILIARY UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 8)
FROM BATTERY (DIAGRAM 1 OF 8)
FRONT ACCESSORY POWER SOCKET RELAY
FUSE
FUSE 1 FUSE 2 (NOT USED)
FUSE 12 FUSE
FUSE 14 (IF EQUIPPED)
FUSE 2
FUSE 3 FUSE 4
FUSE FUSE
GRN WIRE
LEFT SECOND ROW SEAT HEATER RELAY (LOW)
LT GRN WIRE
ORG/ WIRE
PNK PNK PNK PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWER DRIVER'S SEAT POWER SEAT CONTROL ADJUSTMENT UNIT SWITCH
POWER TAILGATE CONTROL UNIT
POWER TAILGATE DRIVER'S POWER SEAT
POWER VTM-4 REAR SEAT RELAY BLOWER CONTROL MOTOR UNIT RELAY
PPL
REAR FUSE/RELAY BOX (LEFT SIDE OF CARGO AREA) LT
RED WIRE
RELAY
RIGHT SECOND ROW SEAT HEATER RELAY (HIGH)
RIGHT SECOND ROW SEAT HEATER RELAY (LOW)
SECOND ROW SEAT HEATERS
TO AUXILIARY UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 8)
TO AUXILIARY UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 3 OF 8)
TRAILER CONNECTOR
TRAILER ELECTRIC BRAKE UNIT CONNECTOR (IF EQUIPPED)
TRAILER LIGHTING CONTROL UNIT
TRAILER TAILLIGHT RELAY
TRAILER)
VSA MODULATOR CONTROL UNIT
W/ DPMS
W/ DPMS W/O DPMS
W/O DPMS
WHT WIRE
Go to component -> Power distribution circuit (2 of 8) -> CONSOLE CONSOLE ACCESSORY ACCESSORY POWER POWER SOCKET B SOCKET A RELAY RELAY
