Honda Pilot II (2008-2011) computer data lines system b-can hi Wiring diagram

+B TPMS BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COMBI GND (LIGHT) COMBI GND (WIPER) COMPUTER DATA LINES SYSTEM B-CAN HI COMPUTER DATA LINES SYSTEM B-CAN LO DIMMER SW DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM G/H DR SW DOOR LOCKS SYSTEM RR WIP RS DRSWDR FR WIPER HIGH, LOW SW FR WIPER MIST SW FUSE G/H SW GRN WIRE GRN/RED WIRE GRY WIRE H/L OFF SW H/L ON SW HEADLIGHT SYSTEM HI H/L RLY HEADLIGHTS SYSTEM HOT AT ALL TIMES IG KEY SW LT BLU WIRE LT GRN WIRE MICU ORG/ WIRE PASSING SW PNK DOOR LOCKS SYSTEM G/H T/G SW WIRE PNK WIRE PPL SIG RED WIRE RED/BLK WIRE RR WASHER SW RR WIPER AS RR WIPER SW SMALL LT SW TRN SIG/HAZ FLSHR CT TRUNK, TAILGATE, FUEL DOOR SYSTEM TURN SW L TURN SW R UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT) WARNING SYSTEM WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE
