Car Wiring Diagrams for Charging circuit for Honda Pilot I facelift (2005-2008)

A/F SENSOR RELAY (BEHIND RIGHT KICK PANEL) AFSHTCR ALT CAN H CAN L ALT CTRL SIG ALT FR SIG ALTERNATOR BATTERY BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE CHARGING SYSTEM INDICATOR COOLING FANS SYSTEMS DRIVER'S UNDER-DASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) ELD IN- PUT ELD UNIT ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEMS FAST CONTROLLER AREA NETWORK TRANSCEIVER FUSE 41 FUSE 6 FUSE 9 GAUGE CONTROL MODULE GRN WIRE GRN/RED WIRE HOT AT ALL TIMES AUXILIARY FUSE 9 FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) HOT IN ON OR START IGNITION COIL RELAY (BEHIND RIGHT KICK PANEL) IN-LINE FUSE 1 MRLY ORG/ WIRE POWER SUPPLY POWERTRAIN CONTROL (PCM) MODULE (RIGHT SIDE OF ENGINE COMPT) REAR OF ENGINE COMPT) RED WIRE RELAY 1 (UNDER LEFT SIDE OF DASH) SIG STARTING CIRCUIT TRANSMISSION UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT) WARNING DRIVE CIRCUIT WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
