Car Wiring Diagrams for Compass circuit for Honda Pilot I facelift (2005-2008)

BLK WIRE DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) ELECTRICAL COMPASS UNIT FUSE 7 HOT IN ON OR START YEL/GRN WIRE
