Back-up lamps circuit for Honda Pilot I facelift (2005-2008)
Back-up lamps circuit
ATPR
BLK WIRE
BRAKE LIGHT FAILURE SENSOR (AT RIGHT SIDE OF CARGO AREA)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BELOW LEFT END OF DASH)
EX-L NAVIGATION SYSTEM
FUSE 9
GAUGE CONTROL MODULE A/T GEAR POSITION INDICATOR
GRN/BLK WIRE
HOT IN ON OR START
JUNCTION CONNECTOR
LEFT BACK-UP LIGHT RIGHT BACK-UP LIGHT
REAR OF ENGINE COMPT)
RED/YEL WIRE
REVERSE RELAY
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION END COVER)
WHT WIRE
