Car Wiring Diagrams for Rear wiper/washer circuit for Honda Pilot I (2004-2009)

AUXILIARY UNDER-HOOD RELAY BOX (RIGHT FRONT OF ENGINE COMPT) BLK WIRE BLK/YEL WIRE BLU/GRN WIRE DRIVER'S MULTIPLEX CONTROL UNIT FR WASH SW DRIVER'S UNDER-DASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) FRONT WASHER MOTOR RELAY (UNDER LEFT SIDE OF DASH) FRONT WIPER CIRCUIT FUSE 12 FUSE 7 GRN WIRE GRN/BLK WIRE GRN/YEL WIRE HOT IN ON OR START LT GRN WIRE LT GRN/BLK WIRE ON OFF WASHER PARK PASSENGER'S MULTIPLEX CONTROL UNIT PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE REAR WASHER MOTOR RELAY (BEHIND RIGHT KICK PANEL) REAR WINDOW WIPER INTERMITTENT RELAY REAR WINDOW WIPER MOTOR (BEHIND LIFTGATE TRIM PANEL) REAR WINDOW WIPER/WASHER SWITCH RED/BLU WIRE RR INT SW RR WIP RLY RR WIP AS RR WASH SW RUN WIRE WASHER WASHER MOTOR (BEHIND RIGHT SIDE OF FRONT BUMPER, ON WASHER RESERVOIR) WHT/BLK WIRE WIPER/WASHER SWITCH YEL WIRE YEL/GRN WIRE
