Rear seat entertainment circuit, lx for Honda Pilot I (2004-2009)

ACCESSORY POWER SOCKET RELAY ANTENNA AMPLIFIER (ON LEFT "C" PILLAR) ANTENNA LEAD CONNECTOR (UNDER CENTER CONSOLE) AUDIO UNIT AUDIO UNIT CONNECTOR BLK WIRE BLK/BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/WHT WIRE CONNECTOR DIM TERMINAL DRIVER'S DOOR SPEAKER DRIVER'S UNDER-DASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) DVD PLAYER UNIT FREQUENCY MODULATOR UNIT (UNDER DRIVER'S SEAT) FRONT PASSENGER'S DOOR SPEAKER FUSE 11 FUSE 48 FUSE 8 FUSE 9 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ACC OR ON I-VES TERMINAL I-VES/MONITOR TERMINAL CONNECTOR INTERIOR LIGHT SWITCH 0=OFF 1=ON 2=DOOR LEFT REAR DOOR SPEAKER NCA WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PASSENGER'S UNDERDASH FUSE/RELAY BOX PPL RR R SPKR (+) RR L SPKR (+) FR AS SPKR (+) FR DR SPKR (+) DIM CTRL + +B PPL/BLK WIRE REAR INDIVIDUAL RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RIGHT REAR DOOR SPEAKER RR R SPKR (-) RR L SPKR (-) FR AS SPKR (-) FR DR SPKR (-) DIM CTRL - GND SIG SH (AM/FM) SWD +B UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPARTMENT) VIDEO MONITOR CONSOLE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE WINDOW ANTENNA YEL WIRE YEL/BLK WIRE
