Honda Pilot I (2004-2009) wen scs k-line Wiring diagram

1 2 MES CONNECTOR BLK WIRE BLU WIRE BRN (OR BLU) WIRE BRN WIRE BRN/YEL WIRE DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH) DIAG DRIVER'S MULTIPLEX CONTROL UNIT DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) GAUGE CONTROL UNIT GRN WIRE GRY (OR BLU) WIRE GRY WIRE HOT AT ALL TIMES IMMOBILIZER CONTROL UNIT- RECEIVER LT BLU WIRE LT GRN/BLK (OR BLU) WIRE LT GRN/BLK WIRE MULTIPLEX CONTROL INSPECTION CONNECTOR (BEHIND LEFT SIDE OF DASH) NAVIGATION SERVICE CHECK CONNECTOR (UNDER RIGHT FRONT SEAT) NAVIGATION UNIT (UNDER RIGHT FRONT SEAT) PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) POWERTRAIN CONTROL (PCM) MODULE (RIGHT SIDE OF ENGINE COMPT) RED WIRE RED/WHT WIRE SIDE TRIM PANEL) SRS UNIT (BEHIND LOWER CENTER OF DASH) TPMS RECEIVER UNIT UNDERHOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT) FUSE 46 VSA MODULATOR CONTROL UNIT (LEFT SIDE OF ENGINE COMPT) VTM-4 CONTROL UNIT (AT LEFT SIDE OF CARGO AREA, BEHIND REAR WEN SCS K-LINE WHT WIRE WHT/GRN WIRE YEL WIRE
