Honda Pilot I (2004-2009) vss out relay ctrl fan ctrl a/c on in relay ctrl fan ctrl sensor gnd sensor in Wiring diagram

A/C CONDENSER FAN MOTOR (FRONT MIDDLE OF ENGINE COMPT) A/C CONDENSER FAN RELAY A/C DIODE A 2 1 A/C DIODE ASSEMBLY (BEHIND RIGHT SIDE OF DASH) A/C DIODE B 3 4 A/C PRESSURE SWITCH BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE ECT SENSOR 1 (REAR OF ENGINE) ENGINE CONTROLS SYSTEM FAN CONTROL RELAY (RIGHT SIDE OF ENGINE COMPT) FUSE 1 FUSE 46 FUSE 57 FUSE 58 GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES IGNITION COIL RELAY (BEHIND RIGHT KICK PANEL) IN-LINE FUSE 1 (BEHIND RIGHT KICK PANEL) MAIN RELAY 1 (UNDER LEFT SIDE OF DASH) NAVIGATION, WIPER/WASHER SYSTEMS POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT) RADIATOR FAN MOTOR (FRONT MIDDLE OF ENGINE COMPARTMENT) RADIATOR FAN RELAY RED WIRE RED/ORG WIRE RED/WHT WIRE TOP OF TRANSMISSION) UNDERHOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPARTMENT) VSS OUT RELAY CTRL FAN CTRL A/C ON IN RELAY CTRL FAN CTRL SENSOR GND SENSOR IN WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE YEL/WHT WIRE
