Honda Pilot I (2004-2009) mirror light Wiring diagram
This page shows the only wiring diagram for the component.mirror light, which is found in the car Honda Pilot I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror light (1 of 1)
AUDIO UNIT
AUXILIARY JACK ASSEMBLY (EX-L, RES (DVD))
BLK WIRE
BRAIDED WIRE
BRAKE LIGHT FAILURE SENSOR
BRN/BLK WIRE
BRN/YEL WIRE
CARGO AREA ACCESSORY POWER SOCKET
DRIVER'S POWER SEAT ADJUSTMENT SWITCH (EX, EX-L)
DRIVER'S SEAT BELT SWITCH
DRIVER'S SEAT DRIVER'S SEAT BACK HEATER HEATER (EX-L)
ELECTRICAL COMPASS UNIT (W/O NAVIGATION) DRIVER'S VANITY MIRROR LIGHT
ENGINE MOUNT CONTROL UNIT
FRONT PASSENGER'S SEAT BELT SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER (EX-L)
FRONT PASSENGER'S VANITY
GAUGE CONTROL MODULE
HIGH MOUNT BRAKE LIGHT
LEFT BACK-UP LIGHT
LEFT SIDE CLUTCH ELECTRO MAGNETIC COIL SHIELD
LEFT TAILLIGHT ASSEMBLY
LICENSE PLATE LIGHT LICENSE PLATE LIGHT
MIRROR LIGHT
MOONROOF CLOSE RELAY
MOONROOF OPEN RELAY
ODS UNIT
REAR CONTROLLER, SCREEN
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER NOISE CONDENSER
REAR WINDOW WIPER MOTOR
RIGHT BACK-UP LIGHT
RIGHT SIDE CLUTCH ELECTRO MAGNETIC COIL SHIELD
RIGHT TAILLIGHT ASSEMBLY
ROOF CONSOLE
TAILGATE LATCH SWITCH
TRAILER LIGHTING CONNECTOR
VTM-4 CONTROL UNIT
Go to component: -> Ground distribution circuit (4 of 4) -> MIRROR LIGHT
