Car Wiring Diagrams for Exterior lamps circuit for Honda Pilot I (2002-2005)

BACK-UP LAMPS CIRCUIT BLK WIRE BRAKE LIGHT/ TAILLIGHT BRAKE PEDAL POSITION SWITCH (AT TOP OF BRAKE PEDAL ARM) DRIVER'S MULTIPLEX CONTROL UNIT FUSE 10 FUSE 10 FUSE 9 FUSE 47 FUSE 49 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES HOT IN ON OR START INTERIOR LIGHTS SYSTEMS LEFT TAILLIGHT ASSEMBLY LICENSE PLATE LIGHT PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) REAR SIDE MARKER LIGHT RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RIGHT TAILLIGHT ASSEMBLY SECURITY CONNECTOR (LX) SML RLY- STOP SW SML RLY+ TAILLIGHT RELAY (BEHIND LEFT SIDE OF DASH) TURN SIGNAL LIGHT/ TAILLIGHT TURN SIGNAL/ HAZARD RELAY UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE

BACK-UP LAMPS CIRCUIT BLK WIRE COMBINATION LIGHT SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD WARNING SWITCH HAZARD WARNING SWITCH LIGHT HEAD HEADLIGHT SWITCH INTERIOR LIGHTS SYSTEMS LEFT FRONT SIDE MARKER LIGHT LEFT FRONT TURN SIGNAL/ PARKING LIGHTS LEFT TURN SIGNAL IND OFF OFF PARK RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL/ PARKING LIGHTS RIGHT TURN SIGNAL IND SAFETY INDICATOR GAUGE ASSEMBLY TRAILER LIGHTING CONNECTOR TURN SIGNAL SWITCH WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/RED WIRE
