Honda Pilot I (2002-2005) ssdc sspc sdv spv wiring diagram
This page shows the only wiring diagram for the component.ssdc sspc sdv spv, which is found in the car Honda Pilot I (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ssdc sspc sdv spv wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL (OR BLU) WIRE
BLU/YEL WIRE
BRN WIRE
BSDL (UNBUCKLED)
BUCKLED
CABLE REEL
DATA LINK CONNECTOR (PARTIAL) (LOWER LEFT SIDE OF DASH)
DRIVER'S AIR BAG FIRST INFLATOR
DRIVER'S AIR BAG SECOND INFLATOR
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S SEAT BELT SWITCH (UNDER DRIVER'S SEAT)
DRIVER'S SIDE AIR BAG INFLATOR
DRIVER'S SIDE IMPACT SENSOR (AT BASE OF LEFT "B" PILLAR)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
FRONT PASSENGER'S SEAT BELT SWITCH (UNDER FRONT PASSENGER SEAT)
FRONT PASSENGER'S SIDE AIR BAG INFLATOR
FRONT PASSENGER'S SIDE IMPACT SENSOR (AT BASE OF RIGHT "B" PILLAR)
FUSE 1
FUSE 2 FUSE 7
FUSE 9
GND A GND B
GRN WIRE
GRN/ORG (OR BLU) WIRE
GRN/ORG WIRE
GRN/WHT (OR BLU) WIRE
GRN/WHT WIRE
GRY/YEL WIRE
HOT IN ON OR START
IGN IN IGN IN
LT BLU WIRE
LT GRN/BLK WIRE
MES CON DIAG-H BSPL BSDL SRS IND SCS BSPH BSDH
MES CONNECTOR
ODUS
RED (OR BLU) WIRE
RED WIRE
RED/BLU (OR BLU) WIRE
RED/BLU WIRE
RED/WHT (OR BLU) WIRE
RED/WHT WIRE
RED/YEL (OR BLU) WIRE
RED/YEL WIRE
SDG SPG SSDH SSPH
SHORT CONTACT
SRPDC SRPPC
SRPDH SRPPH
SRS UNIT (BEHIND LOWER CENTER OF DASH)
SSDC SSPC SDV SPV
STEERING WHEEL)
UN- BUCKLED
UNBUCKLED
WHT WIRE
YEL (OR BLU) WIRE
YEL WIRE
YEL/GRN (OR BLU) WIRE
YEL/GRN WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> SSDC SSPC SDV SPV
