Honda Pilot I (2002-2005) back-up sensor beeper Wiring diagram

This page shows the only wiring diagram for the component.back-up sensor beeper, which is found in the car Honda Pilot I (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram back-up sensor beeper (1 of 1)

Wiring diagram back-up sensor beeper for Honda Pilot I (2002-2005)

Get access

BACK-UP SENSOR BEEPER BACK-UP SENSOR BEEPER SWITCH BACK-UP SENSOR CONTROL UNIT BACK-UP SENSOR IN-LINE FUSE BLK WIRE BLK/BLU WIRE BLK/RED WIRE DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) FUSE 9 GRN WIRE GRN/BLK WIRE GRY WIRE GRY/RED WIRE HOT IN ON OR START LEFT CENTER SENSOR LEFT CORNER SENSOR ON INDICATOR ORG/ WIRE RED WIRE REVERSE RELAY RIGHT CENTER SENSOR RIGHT CORNER SENSOR WHT WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
