Honda Passport III facelift (2021-2024) right seat remote fold down access relay Wiring diagram
This page shows the only wiring diagram for the component.right seat remote fold down access relay, which is found in the car Honda Passport III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right seat remote fold down access relay (1 of 1)
AUDIO REMOTE- HFL SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
BLU WIRE
CABLE REEL
CD PLAYER UNIT
CD PLAYER UNIT (4 PIN CONNECTOR)
CLIMATE CONTROL UNIT
CMBS OFF SWITCH/ RDM SWITCH
CONSOLE BOX LIGHT
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DRIVER'S FOOTWELL LIGHT
DRIVER'S FOOTWELL LIGHT (2 PIN CONNECTOR)
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S VENTILATED SEAT/ SEAT HEATER SWITCH
ECON SWITCH
FROM AUXILIARY UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 10)
FROM FUSE 27 (DIAGRAM 7 OF 10)
FRONT BEVERAGE HOLDER LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S VENTILATED SEAT SWITCH/ SEAT HEATER SWITCH
FUSE 25
FUSE 26
FUSE 37
FUSE 38
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
HEATED WINDSHIELD WIPER AREA/ PARKING, BACKUP SENSOR SWITCH
IDLE STOP OFF SWITCH
JOINT 15
JOINT 16
LEFT REAR RELAY HOLDER B (BEHIND LEFT QUARTERPANEL)
LEFT SEAT REMOTE FOLD DOWN ACCESS RELAY
MICU
POWER MIRROR SWITCH
PPL
REAR CONTROL PANEL
RIGHT SEAT REMOTE FOLD DOWN ACCESS RELAY
ROOF CONSOLE MODULE
SBW SHIFTER CONTROL MODULE
TELEMATICS SWITCH MODULE
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
W/ DOOR ILLUMINATION LIGHT
W/O DOOR ILLUMINATION LIGHT
Go to component -> Power distribution circuit (8 of 10) -> RIGHT SEAT REMOTE FOLD DOWN ACCESS RELAY
