Honda Passport III facelift (2021-2024) right power tailgate pinch sensor Wiring diagram
This page shows the only wiring diagram for the component.right power tailgate pinch sensor, which is found in the car Honda Passport III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power tailgate pinch sensor (1 of 1)
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE UNIT (LEFT SIDE OF TAILGATE)
FUSE 1-4
FUSE 26
FUSE 28
FUSE 6
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
KEYLESS/POWER TAILGATE OUTSIDE BUZZER
LEFT POWER TAILGATE PINCH SENSOR
LT GRN WIRE
MICU
PNK WIRE
POWER TAILGATE CONTROL UNIT
POWER TAILGATE MOTOR
POWER TAILGATE SENSOR
PPL
RED WIRE
RELAY ENERGIZED
RIGHT POWER TAILGATE PINCH SENSOR
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
TRANSMISSIONS SYSTEM
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Power tailgate circuit (1 of 2) -> RIGHT POWER TAILGATE PINCH SENSOR
