Honda Passport III facelift (2021-2024) right front relay holder Wiring diagrams
This page contains all the electrical diagrams for the component. right front relay holder, in which he is found in the car Honda Passport III facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front relay holder (1 of 2)
BLK WIRE
CONSOLE ACCESSORY POWER SOCKET RELAY
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DATA LINK CONNECTOR (DLC)
ENGINE MOUNT CONTROL UNIT
FRONT BLOWER POWER TRANSISTOR
HEADLIGHT LEVELING CONTROL UNIT
HIGH MOUNT BRAKE LIGHT
LEFT FRONT FOG LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT (HIGH)
LEFT LICENSE PLATE LIGHT
PARKING, BACKUP SENSOR CONTROL UNIT
REAR BLOWER POWER TRANSISTOR
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT END OF DASH)
RIGHT FRONT RELAY HOLDER
RIGHT LICENSE PLATE LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT
SECURITY HOOD SWITCH
STEREO AMPLIFIER
TAILGATE LATCH SWITCH/ TAILGATE RELEASE ACTUATOR
TAILGATE OUTER HANDLE SWITCH
TUNER AMPLIFIER UNIT
WASHER FLUID LEVEL SWITCH
WIRELESS CHARGER
Go to component -> Ground distribution circuit (1 of 8) -> RIGHT FRONT RELAY HOLDER
Wiring diagram right front relay holder (2 of 2)
10 SPEAKER
7 SPEAKER
ANC/ACTIVE SOUND CONTROL UNIT
AUTOMATIC LIGHTING/RAIN SENSOR
AUXILIARY UNDER- DASH RELAY HOLDER C
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BRN WIRE
CARGO AREA ACCESSORY POWER SOCKET
CARGO AREA ACCESSORY POWER SOCKET RELAY
COMPUTER DATA LINES SYSTEM
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
DC-DC CONVERTER ACC RELAY
DIODE D
FROM ACC RELAY (DIAGRAM 2 OF 10)
FROM DC-DC CONVERTER (DIAGRAM 6 OF 10)
FROM FUSE 3 (DIAGRAM 2 OF 10)
FROM FUSE 5 (DIAGRAM 1 OF 10)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 10)
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 1
FUSE 2
FUSE 4
FUSE 40
FUSE 5
FUSE 6
FUSE 7
FUSE 8
GRN WIRE
JOINT 4
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
REAR ANC/ ACTIVE SOUND CONTROL MICROPHONE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT RELAY HOLDER
TAILGATE RELEASE ACTUATOR RELAY
TAN WIRE
TELEMATICS CONTROL UNIT
UNDER- DASH FUSE/ RELAY BOX
USB CHARGER UNIT
USB CHARGER UNIT A
USB CHARGER UNIT B
W/ DISPLAY AUDIO
WHT WIRE
WIRELESS CHARGER
Go to component -> Power distribution circuit (5 of 10) -> RIGHT FRONT RELAY HOLDER
