Honda Passport III facelift (2021-2024) left seat remote fold down actuator Wiring diagrams
This page contains all the electrical diagrams for the component. left seat remote fold down actuator, in which he is found in the car Honda Passport III facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left seat remote fold down actuator (1 of 2)
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 26
GRY WIRE
HOT AT ALL TIMES
LEFT REAR RELAY HOLDER B
LEFT SEAT REMOTE FOLD DOWN ACTUATOR
LEFT SEAT REMOTE FOLD DOWN RELAY
LEFT SEAT REMOTE FOLD DOWN SWITCH
LT BLU WIRE
LT GRN WIRE
MICU
PPL
RED WIRE
RIGHT SEAT REMOTE FOLD DOWN ACTUATOR
RIGHT SEAT REMOTE FOLD DOWN RELAY
RIGHT SEAT REMOTE FOLD DOWN SWITCH
UNDER-DASH FUSE/RELAY BOX
Go to component -> Fold down seat circuit -> LEFT SEAT REMOTE FOLD DOWN ACTUATOR
Wiring diagram left seat remote fold down actuator (2 of 2)
BLK WIRE
BRN WIRE
CENTER/LEFT SECOND ROW SEAT BELT BUCKLE SWITCH
FRONT PASSENGER SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BACK HEATER
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER
FRONT SEAT HEATER CONTROL UNIT
FTP SENSOR SHIELD
GRY WIRE
JOINT 5
JOINT 6
LEFT SEAT REMOTE FOLD DOWN ACTUATOR
LEFT SEAT REMOTE FOLD DOWN SWITCH
LEFT SECOND ROW SEAT BACK HEATER
LEFT SECOND ROW SEAT CUSHION HEATER
PASSENGER'S SEAT CUSHION BLOWER MOTOR
PASSENGER'S SEAT-BACK BLOWER MOTOR
REAR CONTROL PANEL
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
RIGHT REAR DOOR POCKET LIGHT
RIGHT REAR POWER WINDOW SWITCH
RIGHT SEAT REMOTE FOLD DOWN ACTUATOR
RIGHT SEAT REMOTE FOLD DOWN SWITCH
RIGHT SECOND ROW SEAT BELT BUCKLE SWITCH
RIGHT SECOND ROW SEAT CUSHION HEATER
SECOND ROW SEAT HEATER CONTROL UNIT
USB CHARGER UNIT B
YEL WIRE
Go to component -> Ground distribution circuit (6 of 8) -> LEFT SEAT REMOTE FOLD DOWN ACTUATOR
