Honda Passport III facelift (2021-2024) left bsi alert indicator Wiring diagrams
This page contains all the electrical diagrams for the component. left bsi alert indicator, in which he is found in the car Honda Passport III facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left bsi alert indicator (1 of 2)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BSI INDICATOR
COMPUTER DATA LINES SYSTEM
FUSE 1
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT W/ DC-DC CONVERTER
LEFT BSI ALERT INDICATOR
LEFT SIDE BSI RADAR UNIT
RIGHT BSI ALERT INDICATOR
RIGHT SIDE BSI RADAR UNIT
TAN WIRE
WHT WIRE
Go to component -> Blind spot monitoring circuit -> LEFT BSI ALERT INDICATOR
Wiring diagram left bsi alert indicator (2 of 2)
ANC/ACTIVE SOUND CONTROL UNIT
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUXILIARY UNDER-DASH RELAY HOLDER C FRONT ACCESSORY POWER SOCKET RELAY
BLK WIRE
BRN WIRE
CABLE REEL
CMBS OFF SWITCH/ RDM SWITCH
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S DOOR POCKET LIGHT
DRIVER'S POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH
DRIVER'S POWER WINDOW MOTOR
DRIVING POSITION MEMORY SWITCH
ECON SWITCH
ELECTRIC STEERING LOCK
FRONT SEAT HEATER RELAY
FUEL FILL DOOR OPENER SWITCH
GAUGE CONTROL MODULE
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
HEATED WINDSHIELD WIPER AREA/ PARKING, BACKUP SENSOR SWITCH
HEATER PAD
LEFT BSI ALERT INDICATOR
LEFT POWER MIRROR
MICU
PADDLE SHIFTER + (UPSHIFT SWITCH)
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
POWER MIRROR CONTROL UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
REAR WINDOW WIPER MOTOR RELAY
STEERING ANGLE SENSOR
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
W/ BLIND SPOT MONITORING
W/ KEYLESS ACCESS
Go to component -> Ground distribution circuit (4 of 8) -> LEFT BSI ALERT INDICATOR
