Honda Passport III facelift (2021-2024) high ind Wiring diagram
This page shows the only wiring diagram for the component.high ind, which is found in the car Honda Passport III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high ind (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DRIVER'S VENTILATED SEAT/ SEAT HEATER SWITCH
FRONT PASSENGER'S VENTILATED SEAT SWITCH/ SEAT HEATER SWITCH
FUSE 23
GRN WIRE
GRY WIRE
HIGH IND
HOT W/
JOINT 14
LOW IND
LT BLU WIRE
LT GRN WIRE
MIDDLE IND
PNK WIRE
RED WIRE
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Front heated seats circuit, w/o ventilation (2 of 2) -> HIGH IND
