Honda Passport III facelift (2021-2024) hazard warning switch/ front passenger's air bag cutoff indicator Wiring diagrams
This page contains all the electrical diagrams for the component. hazard warning switch/ front passenger's air bag cutoff indicator, in which he is found in the car Honda Passport III facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hazard warning switch/ front passenger's air bag cutoff indicator (1 of 2)
ANTI-LOCK BRAKES SYSTEM
AUTO
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
FUSE 27
FUSE 29
FUSE 4
FUSE 5
FUSE 6
FUSE 7
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
HEAD
HEADLIGHT SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/
JOINT 3
LEFT
LEFT FRONT TURN SIGNAL LIGHT
LEFT POWER MIRROR
LEFT REAR TURN SIGNAL LIGHT
LT BLU WIRE
MICU
OFF
ORG/ WIRE
PARK
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD
RIGHT
SIDE TURN SIGNAL LIGHT
TAILLIGHT RELAY
TAN WIRE
TAN/ORG WIRE
TURN SIGNAL SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ POWER TAILGATE
W/O POWER TAILGATE
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
Wiring diagram hazard warning switch/ front passenger's air bag cutoff indicator (2 of 2)
AUDIO REMOTE- HFL SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
BLU WIRE
CABLE REEL
CD PLAYER UNIT
CD PLAYER UNIT (4 PIN CONNECTOR)
CLIMATE CONTROL UNIT
CMBS OFF SWITCH/ RDM SWITCH
CONSOLE BOX LIGHT
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DRIVER'S FOOTWELL LIGHT
DRIVER'S FOOTWELL LIGHT (2 PIN CONNECTOR)
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S VENTILATED SEAT/ SEAT HEATER SWITCH
ECON SWITCH
FROM AUXILIARY UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 10)
FROM FUSE 27 (DIAGRAM 7 OF 10)
FRONT BEVERAGE HOLDER LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S VENTILATED SEAT SWITCH/ SEAT HEATER SWITCH
FUSE 25
FUSE 26
FUSE 37
FUSE 38
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
HEATED WINDSHIELD WIPER AREA/ PARKING, BACKUP SENSOR SWITCH
IDLE STOP OFF SWITCH
JOINT 15
JOINT 16
LEFT REAR RELAY HOLDER B (BEHIND LEFT QUARTERPANEL)
LEFT SEAT REMOTE FOLD DOWN ACCESS RELAY
MICU
POWER MIRROR SWITCH
PPL
REAR CONTROL PANEL
RIGHT SEAT REMOTE FOLD DOWN ACCESS RELAY
ROOF CONSOLE MODULE
SBW SHIFTER CONTROL MODULE
TELEMATICS SWITCH MODULE
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
W/ DOOR ILLUMINATION LIGHT
W/O DOOR ILLUMINATION LIGHT
Go to component -> Power distribution circuit (8 of 10) -> HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
