Honda Passport III facelift (2021-2024) except trailsport trailsport Wiring diagram
This page shows the only wiring diagram for the component.except trailsport trailsport, which is found in the car Honda Passport III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except trailsport trailsport (1 of 1)
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BRAKE LIGHT
BRAKE LIGHTS
BRAKE PEDAL POSITION SWITCH
BRN WIRE
EXCEPT TRAILSPORT
EXCEPT TRAILSPORT TRAILSPORT
FUSE 11
FUSE 2
FUSE 3
GRN WIRE
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
JOINT 3
LED CONTROL UNIT
LEFT LICENSE PLATE LIGHT
LEFT TAILLIGHT
LT BLU WIRE
LT GRN WIRE
OPTIONAL CONNECTOR A
PCM
PPL
REAR SIDE MARKER LIGHT
RED WIRE
RIGHT LICENSE PLATE LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT
TAILLIGHT
TAN WIRE
TAN/ORG WIRE
TRAILSPORT
TRAILSPORT EXCEPT TRAILSPORT
VSA MODULATOR CONTROL UNIT
W/ POWER TAILGATE
W/O POWER TAILGATE
Go to component -> Exterior lamps circuit (2 of 3) -> EXCEPT TRAILSPORT TRAILSPORT
