Honda Passport III facelift (2021-2024) ect sensor 1 Wiring diagram
This page shows the only wiring diagram for the component.ect sensor 1, which is found in the car Honda Passport III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ect sensor 1 (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
ECT SENSOR 1
GRN WIRE
GRY WIRE
ICM
IGNITION COIL 1
IGNITION COIL 2
LT BLU WIRE
LT GRN WIRE
PCM (RIGHT FRONT OF ENGINE COMPT)
PNK WIRE
PPL
PPL/GRY WIRE
PPL/PNK WIRE
RED WIRE
ROCKER ARM OIL CONTROL SOLENOID B (BANK 1)
ROCKER ARM OIL PRESSURE SENSOR
ROCKER ARM OIL PRESSURE SWITCH B (BANK 1)
SPARK PLUG
TAN WIRE
THROTTLE ACTUATOR
THROTTLE OPEN SENSOR
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (5 of 8) -> ECT SENSOR 1
