Honda Passport III facelift (2021-2024) console accessory power socket Wiring diagrams
This page contains all the electrical diagrams for the component. console accessory power socket, in which he is found in the car Honda Passport III facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram console accessory power socket (1 of 2)
AUXILIARY UNDER- DASH RELAY HOLDER D
BLK WIRE
CAN GATEWAY
CLIMATE CONTROL UNIT
CONSOLE ACCESSORY POWER SOCKET
CONSOLE BOX LIGHT
FRONT ACCESSORY POWER SOCKET
FRONT BLOWER MOTOR RELAY
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S DOOR POCKET LIGHT
FRONT PASSENGER'S POWER WINDOW SWITCH
GLOVE BOX LIGHT
IDLE STOP OFF SWITCH
KEYLESS ACCESS/ TPMS CONTROL UNIT
MILLIMETER WAVE RADAR
RADIATOR FAN MOTOR
REAR BLOWER MOTOR RELAY
RIGHT BSI ALERT INDICATOR
RIGHT FRONT FOG LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT POWER MIRROR
SBW SHIFTER CONTROL MODULE
TELEMATICS CONTROL UNIT
USB CHARGER UNIT A
W/ KEYLESS ACCESS
Go to component -> Ground distribution circuit (7 of 8) -> CONSOLE ACCESSORY POWER SOCKET
Wiring diagram console accessory power socket (2 of 2)
10 SPEAKER
7 SPEAKER
ANC/ACTIVE SOUND CONTROL UNIT
AUTOMATIC LIGHTING/RAIN SENSOR
AUXILIARY UNDER- DASH RELAY HOLDER C
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BRN WIRE
CARGO AREA ACCESSORY POWER SOCKET
CARGO AREA ACCESSORY POWER SOCKET RELAY
COMPUTER DATA LINES SYSTEM
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
DC-DC CONVERTER ACC RELAY
DIODE D
FROM ACC RELAY (DIAGRAM 2 OF 10)
FROM DC-DC CONVERTER (DIAGRAM 6 OF 10)
FROM FUSE 3 (DIAGRAM 2 OF 10)
FROM FUSE 5 (DIAGRAM 1 OF 10)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 10)
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 1
FUSE 2
FUSE 4
FUSE 40
FUSE 5
FUSE 6
FUSE 7
FUSE 8
GRN WIRE
JOINT 4
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
REAR ANC/ ACTIVE SOUND CONTROL MICROPHONE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT RELAY HOLDER
TAILGATE RELEASE ACTUATOR RELAY
TAN WIRE
TELEMATICS CONTROL UNIT
UNDER- DASH FUSE/ RELAY BOX
USB CHARGER UNIT
USB CHARGER UNIT A
USB CHARGER UNIT B
W/ DISPLAY AUDIO
WHT WIRE
WIRELESS CHARGER
Go to component -> Power distribution circuit (5 of 10) -> CONSOLE ACCESSORY POWER SOCKET
