Honda Passport III facelift (2021-2024) cmbs off switch Wiring diagram
This page shows the only wiring diagram for the component.cmbs off switch, which is found in the car Honda Passport III facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cmbs off switch (1 of 1)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (IN STEERING COLUMN)
CMBS IND
CMBS OFF SWITCH
CMBS OFF SWITCH/ RDM SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL/ ACC COMBINATION SWITCH
ENGINE MOUNT CONTROL UNIT
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 1
FUSE 26
FUSE 3
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ DC-DC CONVERTER
LKAS IND
LKAS SWITCH
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR
MULTIPURPOSE CAMERA UNIT
PNK WIRE
RDM IND
RDM/LDW SWITCH
RED WIRE
RIGHT END OF DASH)
SPORT
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Multipurpose camera circuit -> CMBS OFF SWITCH
