Honda Passport III facelift (2021-2024) auxiliary under-hood fuse/ relay box Wiring diagrams

This page contains all the electrical diagrams for the component. auxiliary under-hood fuse/ relay box, in which he is found in the car Honda Passport III facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram auxiliary under-hood fuse/ relay box (1 of 3)

Wiring diagram auxiliary under-hood fuse/ relay box for Honda Passport III facelift (2021-2024) (1 of 3)

Get access

AUXILIARY UNDER-HOOD FUSE/ RELAY BOX BLK WIRE BLU WIRE FUSE 23 FUSE 9 GRY WIRE HEATED WINDSHIELD WIPER AREA HEATED WINDSHIELD WIPER AREA RELAY HEATED WINDSHIELD WIPER AREA/PARKING, BACKUP SENSOR SWITCH HOT AT ALL TIMES HOT W/ LT GRN WIRE MICU OFF PNK WIRE PPL PPL PNK WIRE RED WIRE UNDER-DASH FUSE/RELAY BOX W/O PARKING, BACKUP SENSOR WHT WIRE

Go to component -> Heated windshield circuit -> AUXILIARY UNDER-HOOD FUSE/ RELAY BOX

Wiring diagram auxiliary under-hood fuse/ relay box (2 of 3)

Wiring diagram auxiliary under-hood fuse/ relay box for Honda Passport III facelift (2021-2024) (2 of 3)

Get access

AUXILIARY UNDER- DASH FUSE/ RELAY BOX AUXILIARY UNDER-HOOD FUSE/ RELAY BOX BLK WIRE CENTER DISPLAY UNIT COMPUTER DATA LINES SYSTEM DC-DC CONVERTER DC-DC CONVERTER ACC RELAY FUSE 13 FUSE 29 FUSE 40 FUSE 5 FUSE 6 FUSE 7 GRN WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED INFOTAINMENT CONTROL UNIT LT BLU WIRE NCA WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM PPL RED WIRE UNDER- DASH FUSE/ RELAY BOX UNDER- HOOD FUSE/ RELAY BOX USB CHARGER UNIT A USB PORT B (CHARGE ONLY) WHT WIRE YEL WIRE

Go to component -> Navigation circuit, 10 speakers (1 of 5) -> AUXILIARY UNDER-HOOD FUSE/ RELAY BOX
