Honda Passport III (2019-2021) w/ door illumination light Wiring diagrams
This page contains all the electrical diagrams for the component. w/ door illumination light, in which he is found in the car Honda Passport III (2019-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ door illumination light wiring diagram (1 of 2)
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BRN WIRE
CD PLAYER UNIT
CD PLAYER UNIT (4 PIN CONNECTOR)
CLIMATE CONTROL UNIT
CONSOLE BOX LIGHT
DRIVER'S FOOTWELL LIGHT
DRIVER'S FOOTWELL LIGHT (2 PIN CONNECTOR)
DRIVER'S VENTILATED SEAT/ SEAT HEATER SWITCH
FRONT BEVERAGE HOLDER LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S VENTILATED SEAT SWITCH/ SEAT HEATER SWITCH
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
IDLE STOP OFF SWITCH
JOINT 16
JOINT 18
RED WIRE
ROOF CONSOLE MODULE
SBW SHIFTER CONTROL MODULE
SPORT
TELEMATICS SWITCH MODULE
W/ DOOR ILLUMINATION LIGHT
W/O DOOR ILLUMINATION LIGHT
Go to component -> Instrument illumination circuit (2 of 2) -> W/ DOOR ILLUMINATION LIGHT
w/ door illumination light wiring diagram (2 of 2)
AUDIO REMOTE- HFL SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
BLU WIRE
CABLE REEL
CD PLAYER UNIT
CD PLAYER UNIT (4 PIN CONNECTOR)
CLIMATE CONTROL UNIT
CMBS OFF SWITCH/ RDM SWITCH
CONSOLE BOX LIGHT
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DRIVER'S FOOTWELL LIGHT
DRIVER'S FOOTWELL LIGHT (2 PIN CONNECTOR)
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S VENTILATED SEAT/ SEAT HEATER SWITCH
ECON SWITCH
FROM AUXILIARY UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 10)
FROM FUSE 27 (DIAGRAM 7 OF 10)
FRONT BEVERAGE HOLDER LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S VENTILATED SEAT SWITCH/ SEAT HEATER SWITCH
FUSE 25
FUSE 26
FUSE 37
FUSE 38
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
HEATED WINDSHIELD WIPER AREA/ PARKING, BACKUP SENSOR SWITCH
IDLE STOP OFF SWITCH
JOINT 15
JOINT 16
LEFT REAR RELAY HOLDER B (BEHIND LEFT QUARTERPANEL)
LEFT SEAT REMOTE FOLD DOWN ACCESS RELAY
MICU
POWER MIRROR SWITCH
PPL
REAR CONTROL PANEL
RIGHT SEAT REMOTE FOLD DOWN ACCESS RELAY
ROOF CONSOLE MODULE
SBW SHIFTER CONTROL MODULE
TELEMATICS SWITCH MODULE
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
W/ DOOR ILLUMINATION LIGHT
W/O DOOR ILLUMINATION LIGHT
Go to component -> Power distribution circuit (8 of 10) -> W/ DOOR ILLUMINATION LIGHT
