Honda Passport III (2019-2021) tailgate latch switch/tailgate release actuator Wiring diagram
This page shows the only wiring diagram for the component.tailgate latch switch/tailgate release actuator, which is found in the car Honda Passport III (2019-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate latch switch/tailgate release actuator (1 of 1)
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH
FRONT PASSENGER'S DOOR SWITCH
FULL LATCH SWITCH
FUSE 29
GRN WIRE
GRY WIRE
HOT W/
KEYLESS ACCESS/ TPMS CONTROL UNIT
LEFT REAR DOOR SWITCH
LT BLU WIRE
MICU
PARKING BRAKE SWITCH
PCM
PNK W/ POWER TAILGATE WIRE
PNK W/O POWER TAILGATE WIRE
PNK WIRE
POWER TAILGATE CLOSER UNIT
POWER TAILGATE CONTROL UNIT
PPL/GRY WIRE
RIGHT REAR DOOR SWITCH
ROCKER ARM OIL PRESSURE SENSOR
ROCKER ARM OIL PRESSURE SWITCH B (BANK 1)
TAILGATE LATCH SWITCH/TAILGATE RELEASE ACTUATOR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> TAILGATE LATCH SWITCH/TAILGATE RELEASE ACTUATOR
