Honda Passport III (2019-2021) second row wiring diagram
This page shows the only wiring diagram for the component.second row, which is found in the car Honda Passport III (2019-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
second row wiring diagram (1 of 1)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 16
FUSE 23
GRN WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ DC-DC
LEFT FRONT RELAY HOLDER (LEFT KICK PANEL)
LEFT SECOND ROW SEAT
LEFT SECOND ROW SEAT BACK HEATER
LEFT SECOND ROW SEAT CUSHION HEATER
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
REAR CONTROL PANEL
RED WIRE
RELAY 1 ENERGIZED
RIGHT SECOND ROW SEAT
RIGHT SECOND ROW SEAT BACK HEATER
RIGHT SECOND ROW SEAT CUSHION HEATER
SEAT HEATER RELAY
SECOND ROW
SECOND ROW SEAT HEATER CONTROL UNIT
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
Go to component -> Second row heated seats circuit -> SECOND ROW
