Honda Passport III (2019-2021) left seat remote fold down relay wiring diagram
This page shows the only wiring diagram for the component.left seat remote fold down relay, which is found in the car Honda Passport III (2019-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left seat remote fold down relay wiring diagram (1 of 1)
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 26
GRY WIRE
HOT AT ALL TIMES
LEFT REAR RELAY HOLDER B
LEFT SEAT REMOTE FOLD DOWN ACTUATOR
LEFT SEAT REMOTE FOLD DOWN RELAY
LEFT SEAT REMOTE FOLD DOWN SWITCH
LT BLU WIRE
LT GRN WIRE
MICU
PPL
RED WIRE
RIGHT SEAT REMOTE FOLD DOWN ACTUATOR
RIGHT SEAT REMOTE FOLD DOWN RELAY
RIGHT SEAT REMOTE FOLD DOWN SWITCH
UNDER-DASH FUSE/RELAY BOX
Go to component -> Fold down seat circuit -> LEFT SEAT REMOTE FOLD DOWN RELAY
