Honda Passport III (2019-2021) hands free access power tailgate control unit/ sensor Wiring diagram
This page shows the only wiring diagram for the component.hands free access power tailgate control unit/ sensor, which is found in the car Honda Passport III (2019-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hands free access power tailgate control unit/ sensor (1 of 1)
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BRN WIRE
CLOSER MOTOR
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DRIVER'S POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH
FUEL FILL DOOR OPENER SWITCH
FULL LATCH SWITCH
GRN WIRE
GRY WIRE
HALF LATCH SWITCH
HANDS FREE ACCESS POWER TAILGATE CONTROL UNIT/ SENSOR
KEYLESS ACCESS/TPMS CONTROL UNIT
LT BLU WIRE
LT GRN WIRE
NEUTRAL SWITCH
OPTIONAL CONNECTOR A
PNK WIRE
POWER TAILGATE CLOSER UNIT (LOWER CENTER OF TAILGATE)
POWER TAILGATE INSIDE SWITCH
POWER WINDOW MASTER SWITCH
PPL
RATCHET SWITCH
RED WIRE
TAILGATE OUTER HANDLE SWITCH
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Power tailgate circuit (2 of 2) -> HANDS FREE ACCESS POWER TAILGATE CONTROL UNIT/ SENSOR
