Exterior lamps circuit for Honda Passport II (1997-2002)
Exterior lamps circuit (1 of 2)
2 1 3 1 2 3 IGNITION OUTPUT GND
4 1 (ISUZU) (HONDA)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMBINATION SWITCH
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
FLASHER UNIT (ABOVE LEFT KICK PANEL)
FUSE 1 HAZARD
FUSE 15 ELECT IG
FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HAZARD OFF
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HOT AT ALL TIMES
HOT IN ON
LEFT
LEFT FRONT PARKING/ TURN SIGNAL LIGHT
LEFT TURN INDICATOR LIGHT
OFF HAZARD
PNK WIRE
RED WIRE
RIGHT
RIGHT FRONT PARKING/ TURN SIGNAL LIGHT
RIGHT TURN INDICATOR LIGHT
TRAILER LIGHTING CONNECTOR (IN LEFT REAR CARGO COMPARTMENT, TAPED TO HARNESS)
TURN SIGNAL SWITCH
WHT WIRE
Exterior lamps circuit (2 of 2)
4 3 (HONDA) (ISUZU)
4 5 PNK WIRE
BLK WIRE
COMBINATION SWITCH
CRUISE CONTROL, SHIFT INTERLOCK SYSTEMS
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE 4 TAIL/ILLUMI LIGHT
FUSE 6 STOP LIGHT
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HARD TOP
HEAD OFF PARK
HEADLIGHT SWITCH
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
LEFT LICENSE LIGHT
LEFT TAILLIGHT ASSEMBLY TAIL STOP
LICENSE LIGHT
LT BLU WIRE
PNK WIRE
RED WIRE
RIGHT LICENSE LIGHT
RIGHT TAILLIGHT ASSEMBLY
SOFT TOP
TAIL STOP
TAIL/STOP LIGHT
TAILLIGHT RELAY
TRANSMISSION, ANTI-LOCK BRAKES SYSTEMS
TURN LIGHT
W/SPARE TIRE MOUNTED ON TAILGATE
W/SPARE TIRE MOUNTED UNDER REAR OF VEHICLE
WHT WIRE
YEL WIRE
