Anti-theft circuit for Honda Passport II (1997-2002)

ANTI- THEFT FUSE 18 BLK WIRE BLK/BLU WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE COIL DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) DIODE BOX 5 DIODE BOX 6 DOOR LOCKS SYSTEM DOOR/HATCH OPEN IN TAILLIGHT RELAY KEY IN IGNITION DRIVER'S DOOR SWITCH FRONT PASSENGER'S DOOR SWITCH FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHTS SYSTEMS HORN FUSE 2 HOT AT ALL TIMES HOT IN ACC OR ON INTERIOR LIGHTS, WIPER/ WASHER SYSTEMS J/C B KEY REMINDER SWITCH (PART OF IGNITION SWITCH) KEYLESS ENTRY, SECURITY CONTROL UNIT (ABOVE RIGHT KICK PANEL) LEFT REAR DOOR SWITCH LOCK OUTPUT DOOR LOCK POSIT IN DISARM LOCK INPUT LT GRN WIRE LT GRN/RED WIRE LT GRN/WHT WIRE PNK/BLU WIRE POWER DOOR LOCK FUSE 7 POWER INPUT LOCK/UNLOCK SECURITY HORN CTRL DR DOOR ACT CTRL PPL (OR VIO) WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT REAR DOOR SWITCH SECURITY HORN (ON RIGHT SIDE OF ENGINE COMPARTMENT) SECURITY OR ANTI-THEFT INDICATOR LIGHT STARTER RELAY WARNING SYSTEMS WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE

BLK WIRE BLK/RED WIRE BLU/WHT WIRE BLU/YEL WIRE DRIVER'S DOOR KEY DETECT, ACTUATOR POSITION SWITCHES FRONT PASSENGER'S DOOR ACTUATOR POSITION SWITCH GRN/RED WIRE GRN/WHT WIRE LEFT FRONT OR DRIVER'S DOOR KEY DETECT SWITCH LEFT REAR DOOR ACTUATOR POSITION SWITCH LOCK LT GRN WIRE PPL PPL (OR VIO) WIRE RIGHT FRONT OR FRONT PASSENGER'S DOOR KEY DETECT SWITCH RIGHT REAR DOOR ACTUATOR POSITION SWITCH TAILGATE ACTUATOR POSITION SWITCH TAILGATE KEY DETECT SWITCH UNLOCK YEL/BLU WIRE YEL/RED WIRE
