Honda Passport II (1997-2002) wiper rear wiper switch Wiring diagram
This page shows the only wiring diagram for the component.wiper rear wiper switch, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper rear wiper switch (1 of 1)
4 1 3 2 7 BATTERY IGNITION REAR WASH CTRL WIPE MTR CTRL WIPE MTR CTRL
ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
BLK WIRE
BLU WIRE
BRN/WHT WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DOOR LOCKS SYSTEM
FUSE 16 REAR WIPER, WASHER
FUSE 5 DOME LIGHT
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HATCH GATE OPEN SWITCH (ON LATCH ASSEMBLY)
HOT AT ALL TIMES
HOT IN ON
ILLUM
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/BLU WIRE
LT GRN/WHT WIRE
REAR WASHER MOTOR (IN WASHER FLUID RESERVOIR)
REAR WIPER MOTOR (INSIDE RIGHT SIDE OF TAILGATE, BEHIND TRIM PANEL)
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
WASHER
WHT WIRE
WIPER REAR WIPER SWITCH
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Rear washer/wiper circuit -> WIPER REAR WIPER SWITCH
