Honda Passport II (1997-2002) wipe/int ctrl Wiring diagram
This page shows the only wiring diagram for the component.wipe/int ctrl, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wipe/int ctrl (1 of 1)
ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION SWITCH
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE 17 FRONT WIPER, WASHER
HOT IN ON OR START
IGNITION
INT INPUT
INT LO HI
LO HI
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
OFF
OFF INT
PARK
RED WIRE
REF
RUN WIRE
RUN/PARK IN
VAR INT INPUT
VARIABLE INTERMITTENT
WASH
WASH INPUT
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR (ON RIGHT REAR CORNER OF ENGINE COMPT, ON FIREWALL)
WINDSHIELD WIPER/WASHER SWITCH
WIPE/INT CTRL
YEL WIRE
Go to component -> Front washer/wiper circuit -> WIPE/INT CTRL
