Honda Passport II (1997-2002) tailgate door lock actuator Wiring diagrams
This page contains all the electrical diagrams for the component. tailgate door lock actuator, in which he is found in the car Honda Passport II (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tailgate door lock actuator (1 of 2)
9 6 HONDA ISUZU
ANTI- THEFT FUSE
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DOOR LOCK SWITCH
DRIVER'S DOOR LOCK ACTUATOR
DRIVER'S POWER WINDOW, DOOR LOCK SWITCH
FRONT PASSENGER DOOR LOCK ACTUATOR
FRONT PASSENGER'S POWER WINDOW, DOOR LOCK SWITCH
HONDA
HOT AT ALL TIMES
HOT IN ACC OR ON
ISUZU
KEYLESS ENTRY, SECURITY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LT GRN WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
POWER DOOR LOCK FUSE 7
RED WIRE
RED/BLU WIRE
RIGHT REAR DOOR LOCK ACTUATOR
TAILGATE DOOR LOCK ACTUATOR
UNLOCK
WHT WIRE
WHT/RED WIRE
Go to component -> Power door lock circuit, with keyless entry -> TAILGATE DOOR LOCK ACTUATOR
Wiring diagram tailgate door lock actuator (2 of 2)
1 4 HONDA ISUZU
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DOOR LOCK SWITCH
DRIVER'S DOOR LOCK ACTUATOR
DRIVER'S POWER WINDOW, DOOR LOCK SWITCH
FRONT PASS. DOOR LOCK ACTUATOR
FRONT PASSENGER'S POWER WINDOW, DOOR LOCK SWITCH DRIVER'S DOOR KEY SWITCH
HONDA
HOT AT ALL TIMES
ISUZU
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LT GRN WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
POWER DOOR LOCK FUSE 7
RED WIRE
RED/BLU WIRE
RIGHT REAR DOOR LOCK ACTUATOR
TAILGATE DOOR LOCK ACTUATOR
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Power door lock circuit, without keyless entry -> TAILGATE DOOR LOCK ACTUATOR
