Honda Passport II (1997-2002) right front or front passenger's door key detect switch Wiring diagram
This page shows the only wiring diagram for the component.right front or front passenger's door key detect switch, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front or front passenger's door key detect switch (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DRIVER'S DOOR KEY DETECT, ACTUATOR POSITION SWITCHES
FRONT PASSENGER'S DOOR ACTUATOR POSITION SWITCH
GRN/RED WIRE
GRN/WHT WIRE
LEFT FRONT OR DRIVER'S DOOR KEY DETECT SWITCH
LEFT REAR DOOR ACTUATOR POSITION SWITCH
LOCK
LT GRN WIRE
PPL
PPL (OR VIO) WIRE
RIGHT FRONT OR FRONT PASSENGER'S DOOR KEY DETECT SWITCH
RIGHT REAR DOOR ACTUATOR POSITION SWITCH
TAILGATE ACTUATOR POSITION SWITCH
TAILGATE KEY DETECT SWITCH
UNLOCK
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit (2 of 2) -> RIGHT FRONT OR FRONT PASSENGER'S DOOR KEY DETECT SWITCH
