Honda Passport II (1997-2002) power drive indicator light Wiring diagram

2 INDICATOR 3 INDICATOR A/T FLUID INDICATOR LIGHT A/T GEAR POSITION INDICATOR ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CHARGING SYSTEM CHECK TRANS INDICATOR LIGHT CONTROL UNIT (UNDER CENTER CONSOLE) CRUISE CONTROL SYSTEM CRUISE SET INDICATOR LIGHT D INDICATOR DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) DRIVER'S SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE) ENGINE CONTROLS SYSTEM FUSE 11 METER FUSE 13 ECM, BACKUP FUSE 14 BACK UP/ TURN LIGHT FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) GAUGE ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE HEADLIGHTS SYSTEM HIGH BEAM INDICATOR LIGHT HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION (4) L INDICATOR LEFT TURN INDICATOR LIGHT LIGHTS SYSTEM EXTERIOR LT BLU WIRE M/T MULITPLEX CONTROL UNIT (UNDER REAR OF CENTER CONSOLE) N INDICATOR OIL PRESSURE SWITCH (ON LOWER FRONT OF ENGINE, NEAR OIL FILTER) ORG/BLK WIRE P INDICATOR PNK WIRE PNK/BLK WIRE PNK/GRN WIRE PNK/WHT WIRE PNK/YEL WIRE POWER DRIVE INDICATOR LIGHT PPL PPL/WHT WIRE R INDICATOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT TURN INDICATOR LIGHT SUPPLEMENTAL RESTRAINTS SYSTEM UPSHIFT INDICATOR LIGHT VEHICLE SPEED SENSOR (BENEATH CENTER OF VEHICLE, REAR OF TRANSMISSION) WARNING SYSTEM WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WINTER DRIVE INDICATOR LIGHT YEL WIRE YEL/BLK WIRE YEL/PPL WIRE YEL/RED WIRE
