Honda Passport II (1997-2002) left taillight assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left taillight assembly, in which he is found in the car Honda Passport II (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left taillight assembly (1 of 2)
4 6 (HONDA) (ISUZU)
A/T
BACK- UP LIGHT
BACK-UP LIGHT SWITCH
BLK WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE 14 BACK UP/ TURN LIGHT
GRN/WHT WIRE
HOT IN ON OR START
LEFT TAILLIGHT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
M/T
RED WIRE
RED/YEL WIRE
RIGHT TAILLIGHT ASSEMBLY
WHT (OR RED/BLU) WIRE
WHT/GRN WIRE
Go to component -> Back-up lamps circuit -> LEFT TAILLIGHT ASSEMBLY
Wiring diagram left taillight assembly (2 of 2)
ASHTRAY LIGHT
BACK-UP
BLK WIRE
BLU WIRE
CIGARETTE LIGHTER
COIL
COMBINATION SWITCH
DASH FUSE BOX ACCESSORY SOCKET POWER RELAY
DOME LIGHT RELAY (2001)
DRIVER'S POWER WINDOW, DOOR LOCK SWITCH
FAN CONTROL SWITCH
FLASHER UNIT
FRONT ACCESSORY POWER SOCKET
FRONT PASS- ENGER'S DOOR ACTUATOR POSITION SWITCH
FRONT PASS- ENGER'S DOOR KEY CYLINDER SWITCH
FRONT PASS- ENGER'S POWER WINDOW, DOOR LOCK SWITCH
FUEL TANK UNIT
FUSE/ RELAY BOX
GAUGE ASSEMBLY
HIGH-MOUNTED BRAKE LIGHT
ILLUM- INATION CONTROLLER
KEYLESS ENTRY, SECURITY CONTROL UNIT (EX)
LEFT FRONT VANITY MIRROR LIGHT
LEFT LICENSE LIGHT RIGHT LICENSE LIGHT
LEFT MAP LIGHT RIGHT MAP LIGHT
LEFT POWER MIRROR
LEFT REAR DOOR ACTUATOR POSITION SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT TAILLIGHT ASSEMBLY
LICENSE PLATE LIGHT
MAP LIGHT TIMER (2001)
MIRROR CONTROL SWITCH
MOON ROOF CONTROL UNIT
PARK/ STOP TURN
PARKING POSITION DETECT SWITCH
POWER SEAT SWITCH REAR WINDOW DEFOGGER
POWER WINDOW RELAY
REAR ACCESSORY POWER SOCKET
REAR VIEW MIRROR)
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT POWER MIRROR
RIGHT REAR DOOR ACTUATOR POSITION SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT TAILLIGHT ASSEMBLY
SHIFT LOCK SOLENOID
STARTER RELAY (LX)
TAIL STOP TURN
TRAILER LIGHTING CONNECTOR
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> LEFT TAILLIGHT ASSEMBLY
