Honda Passport II (1997-2002) hatch gate open switch Wiring diagram
This page shows the only wiring diagram for the component.hatch gate open switch, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hatch gate open switch (1 of 1)
13 19 (1998 HONDA) (1999-00 HONDA) (ISUZU)
2 1 (HONDA) (ISUZU)
2 2 (HONDA) (ISUZU)
4 3 (HONDA) (ISUZU)
BLK WIRE
BLU WIRE
CARGO AREA LIGHT
CEILIING LIGHT
COMBINATION SWTICH HEADLIGHT SWITCH
DASH FUSE BOX
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) (HONDA) (ISUZU)
DIODE BOX 5
DIODE BOX 6
DOME LIGHT FUSE
DOOR
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR SWITCH
ENGINE CONTROLS SYSTEM
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S DOOR SWITCH
GRN/RED WIRE
GRN/YEL WIRE
HATCH GATE OPEN SWITCH
HEAD OFF PARK
HOT AT ALL TIMES
HOT AT ALL TIMES TAIL/ILLUM LIGHT FUSE
KEYLESS ENTRY, SECURITY CONTROL UNIT (OPTIONAL)
LEFT FRONT VANITY MIRROR LIGHT
LEFT MAP LIGHT
LEFT MAP LIGHT SWITCH
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR SWITCH
LT GRN WIRE
OFF
ON OFF
OPTIONAL
REAR VIEW MIRROR)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT VANITY MIRROR LIGHT 1 2 (HONDA) (ISUZU)
RIGHT MAP LIGHT
RIGHT MAP LIGHT SWITCH
RIGHT REAR DOOR COURTESY LIGHT
RIGHT REAR DOOR SWITCH
TAILLIGHT RELAY
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Courtesy lamps circuit -> HATCH GATE OPEN SWITCH
