Honda Passport II (1997-2002) fuse 6 stop light Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 6 stop light, in which he is found in the car Honda Passport II (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 6 stop light (1 of 3)
1 2 2 1 GROUND BATTERY
ABS INDICATOR LIGHT
BLK WIRE
BLU WIRE
BRAIDED
BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR)
BRAKE PEDAL POSITION SWITCH (BEHIND DASH, ON BRAKE PEDAL SUPPORT)
C-4
C-5
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON RIGHT REAR CORNER OF ENGINE COMPT)
FUSE 11 METER
FUSE 18 ABS
FUSE 6 STOP LIGHT
FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
GAUGE ASSEMBLY
GRN WIRE
GROUND ABS IND LIGHT CTRL
HONDA
HOT AT ALL TIMES
HOT IN ON OR START
I-1 (ISUZU) (HONDA)
INSTRUMENT CLUSTER SYSTEM (BRAKE INDICATOR CIRCUIT)
ISUZU
LEFT FRONT SPEED SENSOR (ON INSIDE OF FRONT WHEEL)
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
PPL
PPL/WHT WIRE
REAR SPEED SENSOR (BENEATH REAR OF VEHICLE, ON TOP OF DIFFERENTIAL)
RED WIRE
RIGHT FRONT SPEED SENSOR (ON INSIDE OF FRONT WHEEL)
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brake circuits -> FUSE 6 STOP LIGHT
Wiring diagram fuse 6 stop light (2 of 3)
4 3 (HONDA) (ISUZU)
4 5 PNK WIRE
BLK WIRE
COMBINATION SWITCH
CRUISE CONTROL, SHIFT INTERLOCK SYSTEMS
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE 4 TAIL/ILLUMI LIGHT
FUSE 6 STOP LIGHT
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HARD TOP
HEAD OFF PARK
HEADLIGHT SWITCH
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
LEFT LICENSE LIGHT
LEFT TAILLIGHT ASSEMBLY TAIL STOP
LICENSE LIGHT
LT BLU WIRE
PNK WIRE
RED WIRE
RIGHT LICENSE LIGHT
RIGHT TAILLIGHT ASSEMBLY
SOFT TOP
TAIL STOP
TAIL/STOP LIGHT
TAILLIGHT RELAY
TRANSMISSION, ANTI-LOCK BRAKES SYSTEMS
TURN LIGHT
W/SPARE TIRE MOUNTED ON TAILGATE
W/SPARE TIRE MOUNTED UNDER REAR OF VEHICLE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> FUSE 6 STOP LIGHT
Wiring diagram fuse 6 stop light (3 of 3)
ANTI-LOCK BRAKES, TRANSMISSIONS SYSTEMS
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
EXTERIOR LIGHTS, CRUISE CONTROL SYSTEMS
FUSE 11 METER
FUSE 6 STOP LIGHT
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
PARK POSITION DETECT SWITCH (BELOW SHIFT LEVER COVER)
RED WIRE
SHIFT LOCK RELAY (BELOW SHIFT LEVER)
SHIFT LOCK SOLENOID (BELOW SHIFT LEVER COVER)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> FUSE 6 STOP LIGHT
